Fluid FS 2 24|BLACK/GREY|24″

“These bikes are shipped unassembled. Bikes should be assembled by an authorized bicycle retailer.”

The Fluid FS 2 24 is an aggressive trail bike designed to tackle demanding trails.

The quality and build reflect everything we put into our full-size bikes, so you know the new Fluid FS Youth is up for every trail they are, and its quality parts will keep it out of the shop.

The Fluid 2 FS 24 features progressive handling, low standover, youth-tuned suspension and a dropper that is optimized for 9-12-year-old riders below 90 pounds.

• Holisticdesign for real, uncompromisedperformance.
• Suspension components built for young riders.
• Designed to fit small and perform big.
• Adult quality and durability, but built to fit.

Frameset

FRAME 6061 Alloy Frame, 120mm Travel, Tapered Head Tube, ISCG05 Mount FORK Manitou Machete J-Unit Comp 24″, 145mm Travel REAR SHOCK X-Fusion 02 Pro R, 170x35mm

Drivetrain

REAR SHIFTER Box Four Multi REAR DERAILLEUR Box Four Wide CRANKSET Alloy Two Piece, 28T Narrow Wide, 140mm BOTTOM BRACKET BSA Threaded CASSETTE Box Four, 11-42T, 8 Speed CHAIN Box Four 8 Spd Chain

Brakes

FRONT BRAKE Tektro HD-J285 Hydraulic, Organic Pads FRONT BRAKE ROTOR Tektro 160mm REAR BRAKE Tektro HD-J285 Hydraulic, Organic Pads REAR BRAKE ROTOR Tektro 160mm BRAKE LEVERS Tektro 2-Finger Jr.

Components

HANDLEBAR 6061 Aluminum, 660mm, 15mm Rise STEM 6061 Alloy, 35mm Length, 31.8mm Clamp SEATPOST TranzX YSP18B, 31.6mm, 100mm, Kid’s Tune HEADSET Sealed Cartridge Bearing, Tapered SADDLE Norco Youth GRIPS Jr. Lock-On PEDALS VP-225 Jr. Flat

Wheels

FRONT HUB Bear Pawls 15x110mm Boost, 32H, 6 Bolt REAR HUB Bear Pawls 12×148 Boost, 32H, HG, 6 Bolt RIMS Stan’s Flow K 24″, 32H FRONT TIRE Maxxis Minion DHF EXO/TR 2.4″ REAR TIRE Maxxis Minion DHR II EXO/TR 2.3″ REAR HUB SKEWER – SPOKES/NIPPLES Stainless, Black

Geometry

Wheel Size 24″ Travel (mm front/mm rear) 145/120 Reach 350 Stack 531 HTA Head Tube Angle 64.5 OS Fork Offset 40 ST Seat Tube Length 305 STA Effective Seat Tube Angle 75.0 RC Rear Centre Length 407 BB Bottom Bracket Rise/Drop -5 BBH Bottom Bracket Height 305 HTT Horizontal Top Tube 492 WB Wheelbase 1052 SOH Standover 569 HT Head Tube Length 100 Trail 106 Recommended Seatpost Drop 100 Maximum Post Insertion 160 Stem Length 35 Crank Length 152 Tire Size 2.35″ – 2.6″
